Axio Observer 5
ZEISS Axio Observer for Life Sciences. Your open and flexible inverted microscope platform
Inverted microscope Axio Observer 5
Item no.: 491916-0002-000 (individual configuration)Inverted microscope Axio Observer 5 for transmitted-light brightfield LED, phase contrast, different...
Inverted microscope Axio Observer 5
Item Number: 491916-0002-000 (individual configuration) Reset configurationTip
Current configuration
-
Microscope stand Axio Observer 5
Item no.: 431006-9901-000Microscope stand Axio Observer 5
Item Number: 431006-9901-000Microscope stand Axio Observer 5 - 6-position nosepiece, H DIC M27 cod. - manual focus drive incl. focus stop - z-drive operation, flat; left - 1x tube lens to fit with optional available 1-position tube lens mount or 3-position optovar turret cod. - slider mount for PlasDIC and analyzer module - circular operation key unit right - keys for switching TL/RL illumination - light manager - interfaces: 1x CAN, 1x RS 232, 1x USB and 1x TCP/IP - trigger socket (In/Out) for shutter - connecting socket for external UNIBLITZ shutter - integrated 12V DC 100W power supply, stabilized, 100V-127V and 200V-240VAC / 50-60Hz / max. 300VA - USB cable and country-specific line cable
-
Path deflection to the tube
Item no.: 000000-1069-227Path deflection to the tube
Item Number: 000000-1069-227Path deflection to the tube for visual observation
-
Sideport 60N L, 3 switching positions
Item no.: 425152-0000-000Sideport 60N L, 3 switching positions
Item Number: 425152-0000-000Sideport 60N L, 3 switching positions (100% vis : 0% L / 0% vis : 100% L / 50% vis : 50% L)
-
1-position tube lens mount, fixed
Item no.: 431010-0000-0001-position tube lens mount, fixed
Item Number: 431010-0000-0001-position tube lens mount, fixed
-
Aqua Stop II
Item no.: 431716-0000-000Aqua Stop II
Item Number: 431716-0000-000Aqua Stop II for Axio Observer, Axiovert 5 and Axiovert 200
-
FL attenuator, discrete
Item no.: 423647-0000-000FL attenuator, discrete
Item Number: 423647-0000-000FL attenuator, discrete Insert for the aperture stop plane of reflected-light illuminators. Filter wheel with 6 positions. Pos. 1: clear aperture. Pos. 2-6: transmission appr. 70, 50, 40, 20 and 2%.
-
6-position reflector turret cod. for P&C modules
Item no.: 424946-0000-0006-position reflector turret cod. for P&C modules
Item Number: 424946-0000-0006-position reflector turret cod. for P&C modules reflector modules exchangable without removal of reflector turret
-
Protection filter for reflector turret
Item no.: 000000-1068-113Protection filter for reflector turret
Item Number: 000000-1068-113Protection filter for reflector turret
-
Carrier for transmitted-light illumination with LCD display
Item no.: 423922-0000-000Carrier for transmitted-light illumination with LCD display
Item Number: 423922-0000-000Carrier for transmitted-light illumination with LCD display and light manager, carrier tiltable, for the mounting of condensers. Equipped with luminous-field diaphragm, 3-position filter changer and attachment possibility for micromanipulators. LCD display, four lines for display of nosepiece position, objective magnification, contrasting techniques, reflector turret equipment and lamp brightness.
-
Reflected-light illuminator FL
Item no.: 423606-9901-000Reflected-light illuminator FL
Item Number: 423606-9901-000Reflected-light illuminator FL - slider mounts for manual sliders - slider mount for 3-position filter slider, dia. 25 mm - beam path apochromatic corrected - transmission from 375 to 825 nm >80%
-
Shutter FL, internal for stands Axio Observer 3 / 5 / 7 / D1 / Z1
Item no.: 423625-0000-000Shutter FL, internal for stands Axio Observer 3 / 5 / 7 / D1 / Z1
Item Number: 423625-0000-000Shutter FL, internal for stands Axio Observer 3 / 5 / 7 / D1 / Z1 for reflected-light illumination switching time < 60 ms switching frequency max. 5 Hz
-
Antiglare screen for Axio Observer/Axiovert 200
Item no.: 000000-1109-741Antiglare screen for Axio Observer/Axiovert 200
Item Number: 000000-1109-741Antiglare screen for Axio Observer/Axiovert
-
Iris stop slider for incident-light equipment
Item no.: 000000-1062-360Iris stop slider for incident-light equipment
Item Number: 000000-1062-360Iris stop slider for incident-light equipment centerable, can be used as luminous-field diaphragm and/or aperture diaphragm slider (Köhler-type illumination in incident-light beam path)
-
Reflector module FL EC P&C
Item no.: 424931-0000-000Reflector module FL EC P&C
Item Number: 424931-0000-000Reflector module FL EC P&C Reflection avoided through tilted mount for emission filters, max. filter thickness: 5 mm
-
Illuminator microLED 3
Item no.: 423053-9074-000Illuminator microLED 3
Item Number: 423053-9074-000Illuminator microLED 3 for mounting on the lamp interface for transmitted-light or reflected-light illumination - colour temperature 5700 K - colour rendering index >90
-
Illumination adapter for light guide (D)
Item no.: 423302-0000-000Illumination adapter for light guide (D)
Item Number: 423302-0000-000Illumination adapter for light guide (D) Suitable for HXP 120 and X-Cite 120, coupling diameter of light guide 5 mm
-
Illuminator HXP 120 V (D)
Item no.: 423013-9010-000Illuminator HXP 120 V (D)
Item Number: 423013-9010-000Illuminator HXP 120 V (D) inclusive built in power supply, lamp module and infrared filter. Fluorescence light source with motorized brightness switch and integrated motorized shutter, that works stepper motor controlled, fast and vibration free. With CAN connection for switching the shutter and the motorized brightness switch via ZEN (blue edition) and ZEN 2 (black edition). Interfaces: - 1x CAN (CAN-HD15) - 1x Trigger in (BNC) - 1x Trigger out (BNC) - 1x EXT (BNC) for remote control unit The package includes light guide, cable BNC and cable CAN.
-
DIC slider LD PN 20x/0.40 II
Item no.: 426954-0000-000DIC slider LD PN 20x/0.40 II
Item Number: 426954-0000-000DIC slider LD PN 20x/0.40 II
-
DIC slider LD PN 40x/0.60 II
Item no.: 426955-0000-000DIC slider LD PN 40x/0.60 II
Item Number: 426955-0000-000DIC slider LD PN 40x/0.60 II
-
Analyzer module DIC ACR P&C for transmitted light
Item no.: 424921-9901-000Analyzer module DIC ACR P&C for transmitted light
Item Number: 424921-9901-000Analyzer module DIC ACR P&C for transmitted light optimized for DIC in transmitted light, not suitable for polarization
-
Mechanical stage 130x85 R/L
Item no.: 432016-9902-000Mechanical stage 130x85 R/L
Item Number: 432016-9902-000Mechanical stage 130x85 R/L for mounting frames K 160 x 110 mm and Z-PIEZO, compatible with objectives autocorr
-
Universal mounting frame K
Item no.: 451352-0000-000Universal mounting frame K
Item Number: 451352-0000-000Universal mounting frame K for: - Petri dishes dia. 24...68 mm - slides (max. length 120 mm) frame size 160 x 110 mm
-
Binocular tube 45°/23
Item no.: 425537-0000-000Binocular tube 45°/23
Item Number: 425537-0000-000Binocular tube 45°/23 with manual shutter
-
Conversion filter 5700-3200 K, d=32 mm
Item no.: 427809-9000-000Conversion filter 5700-3200 K, d=32 mm
Item Number: 427809-9000-000Conversion filter 5700-3200 K, d=32 mm for adapting the LED light to the color impression of halogen light
-
Filter set 38 Endow GFP shift free (E)
Item no.: 000000-1031-346Filter set 38 Endow GFP shift free (E)
Item Number: 000000-1031-346Filter set 38 Endow GFP shift free (E) EX BP 470/40, BS FT 495, EM BP 525/50
-
Filter set 43 Cy 3, d=25 shift free (E)
Item no.: 000000-1114-101Filter set 43 Cy 3, d=25 shift free (E)
Item Number: 000000-1114-101Filter set 43 Cy 3, d=25 shift free (E) EX BP 545/25, BS FT 570, EM BP 605/70
-
Filter set 45 HQ TexasRed, d=25 shift free (E)
Item no.: 000000-1114-462Filter set 45 HQ TexasRed, d=25 shift free (E)
Item Number: 000000-1114-462Filter set 45 HQ TexasRed, d=25 shift free (E) EX BP 560/40, BS FT 585, EM BP 630/75
-
Filter set 49 DAPI shift free (E)
Item no.: 488049-9901-000Filter set 49 DAPI shift free (E)
Item Number: 488049-9901-000Filter set 49 DAPI shift free (E) EX G 365, BS FT 395, EM BP 445/50
-
Filter set 50 Cy 5 shift free (E)
Item no.: 488050-9901-000Filter set 50 Cy 5 shift free (E)
Item Number: 488050-9901-000Filter set 50 Cy 5 shift free (E) EX BP 640/30, BS FT 660, EM BP 690/50
-
Eyepiece PL 10x/23 Br. foc.
Item no.: 444036-9000-000Eyepiece PL 10x/23 Br. foc.
Item Number: 444036-9000-000Eyepiece PL 10x/23 Br. foc.
-
Auxiliary microscope, d=30
Item no.: 444830-9902-000Auxiliary microscope, d=30
Item Number: 444830-9902-000Auxiliary microscope, d=30 to adjust the phase rings and darkfield stop in the condenser
-
Eyepiece eyecup
Item no.: 444801-0000-000Eyepiece eyecup
Item Number: 444801-0000-000Eyepiece eyecup
-
Objective LD Plan-Neofluar 20x/0.4 Corr Ph2 M27
Item no.: 421351-9972-000Objective LD Plan-Neofluar 20x/0.4 Corr Ph2 M27
Item Number: 421351-9972-000Objective LD Plan-Neofluar 20x/0.4 Corr Ph2 M27 (CG=0-1.5mm) (FWD=8.4mm at CG=0mm and FWD=7.4mm at CG=1.5mm)
-
Objective LD Plan-Neofluar 40x/0.6 Corr Ph2 M27
Item no.: 421361-9971-000Objective LD Plan-Neofluar 40x/0.6 Corr Ph2 M27
Item Number: 421361-9971-000Objective LD Plan-Neofluar 40x/0.6 Corr Ph2 M27 (CG=0-1.5mm) (FWD=3.3mm at CG=0mm and FWD=2.5mm at CG=1.5mm)
-
Objective LD A-Plan 10x/0.25 Ph1 M27
Item no.: 421241-9910-000Objective LD A-Plan 10x/0.25 Ph1 M27
Item Number: 421241-9910-000Objective LD A-Plan 10x/0.25 Ph1 M27 (FWD=8.5mm at CG=1mm polystyrene)
-
LD condenser 0.55 H, Ph1, Ph2, Ph3, DIC, DIC; 6 positions
Item no.: 424242-0000-000LD condenser 0.55 H, Ph1, Ph2, Ph3, DIC, DIC; 6 positions
Item Number: 424242-0000-000LD condenser 0.55 H, Ph1, Ph2, Ph3, DIC, DIC; 6 positions with aperture diaphragm, WD=26mm For objective magnifications 4.0x-100x
-
Condenser module DIC II/0.55 with polarizer
Item no.: 426720-0000-000Condenser module DIC II/0.55 with polarizer
Item Number: 426720-0000-000Condenser module DIC II/0.55 with polarizer
-
Dust cover for Axio Observer / Axiovert 200/200M
Item no.: 459330-0000-000Dust cover for Axio Observer / Axiovert 200/200M
Item Number: 459330-0000-000Dust cover for Axio Observer / Axiovert 200/200M (L600xB420xH620 mm)
