- Inverted microscope Axio Observer 5

Axio Observer 5
ZEISS Axio Observer for Life Sciences. Your open and flexible inverted microscope platform
Inverted microscope Axio Observer 5
Item no.: 491916-0001-000 (individual configuration)Inverted microscope Axio Observer 5 for transmitted-light brightfield LED and differential interfere...
Inverted microscope Axio Observer 5
Item Number: 491916-0001-000 (individual configuration) Reset configurationTip
Current configuration
-
Microscope stand Axio Observer 5
Item no.: 431006-9901-000Microscope stand Axio Observer 5
Item Number: 431006-9901-000Microscope stand Axio Observer 5 - 6-position nosepiece, H DIC M27 cod. - manual focus drive incl. focus stop - z-drive operation, flat; left - 1x tube lens to fit with optional available 1-position tube lens mount or 3-position optovar turret cod. - slider mount for PlasDIC and analyzer module - circular operation key unit right - keys for switching TL/RL illumination - light manager - interfaces: 1x CAN, 1x RS 232, 1x USB and 1x TCP/IP - trigger socket (In/Out) for shutter - connecting socket for external UNIBLITZ shutter - integrated 12V DC 100W power supply, stabilized, 100V-127V and 200V-240VAC / 50-60Hz / max. 300VA - USB cable and country-specific line cable
-
Path deflection to the tube
Item no.: 000000-1069-227Path deflection to the tube
Item Number: 000000-1069-227Path deflection to the tube for visual observation
-
Sideport 60N L, 3 switching positions
Item no.: 425152-0000-000Sideport 60N L, 3 switching positions
Item Number: 425152-0000-000Sideport 60N L, 3 switching positions (100% vis : 0% L / 0% vis : 100% L / 50% vis : 50% L)
-
1-position tube lens mount, fixed
Item no.: 431010-0000-0001-position tube lens mount, fixed
Item Number: 431010-0000-0001-position tube lens mount, fixed
-
Aqua Stop II
Item no.: 431716-0000-000Aqua Stop II
Item Number: 431716-0000-000Aqua Stop II for Axio Observer, Axiovert 5 and Axiovert 200
-
6-position reflector turret cod. for P&C modules
Item no.: 424946-0000-0006-position reflector turret cod. for P&C modules
Item Number: 424946-0000-0006-position reflector turret cod. for P&C modules reflector modules exchangable without removal of reflector turret
-
Carrier for transmitted-light illumination with LCD display
Item no.: 423922-0000-000Carrier for transmitted-light illumination with LCD display
Item Number: 423922-0000-000Carrier for transmitted-light illumination with LCD display and light manager, carrier tiltable, for the mounting of condensers. Equipped with luminous-field diaphragm, 3-position filter changer and attachment possibility for micromanipulators. LCD display, four lines for display of nosepiece position, objective magnification, contrasting techniques, reflector turret equipment and lamp brightness.
-
Illuminator microLED 3
Item no.: 423053-9074-000Illuminator microLED 3
Item Number: 423053-9074-000Illuminator microLED 3 for mounting on the lamp interface for transmitted-light or reflected-light illumination - colour temperature 5700 K - colour rendering index >90
-
DIC slider LD PN 20x/0.40 II
Item no.: 426954-0000-000DIC slider LD PN 20x/0.40 II
Item Number: 426954-0000-000DIC slider LD PN 20x/0.40 II
-
DIC slider LD PN 40x/0.60 II
Item no.: 426955-0000-000DIC slider LD PN 40x/0.60 II
Item Number: 426955-0000-000DIC slider LD PN 40x/0.60 II
-
Analyzer module DIC ACR P&C for transmitted light
Item no.: 424921-9901-000Analyzer module DIC ACR P&C for transmitted light
Item Number: 424921-9901-000Analyzer module DIC ACR P&C for transmitted light optimized for DIC in transmitted light, not suitable for polarization
-
Mechanical stage 130x85 R/L
Item no.: 432016-9902-000Mechanical stage 130x85 R/L
Item Number: 432016-9902-000Mechanical stage 130x85 R/L for mounting frames K 160 x 110 mm and Z-PIEZO, compatible with objectives autocorr
-
Universal mounting frame K
Item no.: 451352-0000-000Universal mounting frame K
Item Number: 451352-0000-000Universal mounting frame K for: - Petri dishes dia. 24...68 mm - slides (max. length 120 mm) frame size 160 x 110 mm
-
Binocular tube 45°/23
Item no.: 425537-0000-000Binocular tube 45°/23
Item Number: 425537-0000-000Binocular tube 45°/23 with manual shutter
-
Conversion filter 5700-3200 K, d=32 mm
Item no.: 427809-9000-000Conversion filter 5700-3200 K, d=32 mm
Item Number: 427809-9000-000Conversion filter 5700-3200 K, d=32 mm for adapting the LED light to the color impression of halogen light
-
Eyepiece PL 10x/23 Br. foc.
Item no.: 444036-9000-000Eyepiece PL 10x/23 Br. foc.
Item Number: 444036-9000-000Eyepiece PL 10x/23 Br. foc.
-
Auxiliary microscope, d=30
Item no.: 444830-9902-000Auxiliary microscope, d=30
Item Number: 444830-9902-000Auxiliary microscope, d=30 to adjust the phase rings and darkfield stop in the condenser
-
Eyepiece eyecup
Item no.: 444801-0000-000Eyepiece eyecup
Item Number: 444801-0000-000Eyepiece eyecup
-
Objective LD Plan-Neofluar 20x/0.4 Corr M27
Item no.: 421350-9971-000Objective LD Plan-Neofluar 20x/0.4 Corr M27
Item Number: 421350-9971-000Objective LD Plan-Neofluar 20x/0.4 Corr M27 (CG=0-1.5mm) (FWD=8.4mm at CG=0mm and FWD=7.4mm at CG=1.5mm)
-
Objective LD Plan-Neofluar 40x/0.6 Corr M27
Item no.: 421360-9971-000Objective LD Plan-Neofluar 40x/0.6 Corr M27
Item Number: 421360-9971-000Objective LD Plan-Neofluar 40x/0.6 Corr M27 (CG=0-1.5mm) (FWD=3.3mm at CG=0mm and FWD=2.5mm at CG=1.5mm)
-
Objective LD A-Plan 10x/0.25 Ph1 M27
Item no.: 421241-9910-000Objective LD A-Plan 10x/0.25 Ph1 M27
Item Number: 421241-9910-000Objective LD A-Plan 10x/0.25 Ph1 M27 (FWD=8.5mm at CG=1mm polystyrene)
-
LD condenser 0.55 H, Ph1, Ph2, Ph3, DIC, DIC; 6 positions
Item no.: 424242-0000-000LD condenser 0.55 H, Ph1, Ph2, Ph3, DIC, DIC; 6 positions
Item Number: 424242-0000-000LD condenser 0.55 H, Ph1, Ph2, Ph3, DIC, DIC; 6 positions with aperture diaphragm, WD=26mm For objective magnifications 4.0x-100x
-
Condenser module DIC II/0.55 with polarizer
Item no.: 426720-0000-000Condenser module DIC II/0.55 with polarizer
Item Number: 426720-0000-000Condenser module DIC II/0.55 with polarizer
-
Dust cover for Axio Observer / Axiovert 200/200M
Item no.: 459330-0000-000Dust cover for Axio Observer / Axiovert 200/200M
Item Number: 459330-0000-000Dust cover for Axio Observer / Axiovert 200/200M (L600xB420xH620 mm)
