Microscope stand Axiolab 5, TL, 5x H encoded, stage 75x30 R
Microscope stand Axiolab 5, TL, 5x H encoded, mechanical stage 75x30 R - Z-drive with fine drive knob left and fine drive disk right, flat with scale - 15 mm focus lift - nosepiece 5x brightfield, M27 coded - stage and condenser carrier - mechanical stage 75x30 R with hardcoat anodized surface, 210 x 145 mm stage plate, covered X-guide positioned at bottom, right drive 135 mm (extendable by 15 mm) with friction setting - specimen holder for one-hand operation, spring lever left - transmitted-light illumination with white LED 10W, optional for halogen reflector lamp 12V 35W - integrated 24V DC 60W power unit, stabilized 100...240V AC/ 50...60Hz - country-specific power cable - ECO mode and light management control button - Snap button supports ZEISS Axiocam - USB 2.0 to PC - dust cover - filter holder in TL
Microscopy Camera Axiocam 208 color Most versatile color camera for education, documentation and routine applications with standalone capability, USB3.0 and Ethernet connectivity with 64bit driver software for: ZEN (blue and core), Labscope and TWAIN plugin. Camera package contains the following accessories: - USB 3.0 hub Type-C, - USB 3.0 flash drive, Type-C and Type-A - USB 3.0 cable Type-C to Type-A - Power <(>&<)> signal cable camera to microscope stand compatible with Axiolab 5 and Axioscope 5/7/Vario - Power adapter with country-specific plug Sensor: Sony CMOS image sensor Color, Rolling Shutter Number of Pixel: 3840 (H) x 2160 (V) = 8.3MP, Ultra HD (4K) Selectable Resolution: 3840 x 2160 = Ultra HD (4K) and 1920 x 1080 = Full HD (1080p) Pixel size: 1.85 µm x 1.85 µm Effective Area: 7.1 mm x 4.0 mm, equivalent to 1/2.1" (8.1 mm diagonal) Spectral range: approx. 400 nm – 700 nm, IR filter; RGB Bayer color mask Control buttons on camera for stand-alone use: 1x Image capture 1x OSD (On Screen Display menu) 1x Camera factory reset Status-LED for camera: color coded operation status Stand-alone: Image storage format: TIFF or JPG Video stream format: mp4 Live frame rate via HDMI: 30 fps @ 4K/1080p (also with HDR) Live frame rate through software via Ethernet or USB 3.0 (depending on hardware and software configuration), Exp. Time 1 ms: H x V Frame rate 3840 x 2160 up to 15 fps (ZEN blue edition) 1920 x 1080 up to 27 fps (ZEN blue edition) 1920 x 1080 up to 30 fps (Labscope) Digitization: 24-bit (3 x 8-bit RGB) A/D conversion Integration time: 0.06 ms up to 1 s Gain: 1x - 22x Interfaces for Communication and for Power: HDMI for monitor USB 3.0 Type C for USB hub, flashdrive, Wi-Fi adapter or, PC connection Ethernet (RJ45) for LAN connection Micro-D for power and communication with dedicated stands Optical interface: C-mount Max. file size per image: .tiff up to: 24 MB (not content dependent) .jpg up to: approx.0.5 MB – 3.3 MB (content dependent) Size/Weight: approx. 135 x 97 x 54mm / 590 g Housing: blue painted aluminum and cooling fins on the top plate Registration: CE, RoHS, CSA Power supply: via Micro-D interface Power consumption: 9 W (24 V DC,0.375 A) Environmental conditions: +10°C to +40°C, max. 75% relative air humidity at 35°C, no condensation, free air circulation required, indoor use Supported Operating systems: for ZEN: Windows 10 x64 and higher for Labscope: Windows 10 x64 and higher, iOS v11 and higher, Android 9.0 and higher Supported Application Software: ZEN v3.0 (blue edition) and higher ZEN core v2.7 and higher Labscope v2.9.1 and higher (Windows)/ v2.8.3 and higher (iOS), v4.0 and higher (Android) TWAIN plugin: Software interface to control camera by 3rd party application software The camera is network-enabled and can be used with the ZEISS iOS App, Android APP and ZEISS Labscope software. The Apps are available as a free download from the Apple® App Store, Google Play Store or ZEISS Portal. Unless otherwise stated by the distributor, iPad® and WLAN router are not supplied by ZEISS. Apple®, Apple iPad® are registered trademarks of Apple Inc.
