Objective LD

Objective LD "A-Plan" 32x/0.40 Ph1 Var1

Item no.: 441251-9920-000
Description

Objective LD A-Plan 32x/0.4 Ph1 Var1 (D=0.6-1.4mm) (WD=3.2mm at D=1mm)

Full Description

For this objective is available a cover glas cap (order number 422902-9901-000) for cover glass thickness from 0.17 to 0.6 mm.

Magnification 32x
Numerical Aperture 0.4
Free Working Distance [mm] 3.2 at cover glass 1.0
Coverglass Thickness [mm] 0.6 - 1.4
Thread Type W0.8x1/36"
Immersion Without Immersion
Field of View [mm] 23
Parfocal Length [mm] 45.34
Long Distance Yes
Correction Ring
Iris
Optical System Infinity Color Corrected System (ICS)
Flatness
Color Correction
Biomedical Applications
Fluorescence Yes
- Multichannel
- Ultraviolet Transmission
- Infra Red Transmission
BrightField Yes
Differential Interference Contrast
High Contrast DIC
Polarization-Optical DIC
Phase Contrast Ph 1
VAREL Contrast Varel 1
Hoffman Modulation Contrast
Polarization Contrast
Materials (Reflected Light) Applications
BrightField Yes
BrightField/DarkField
Reflected Light DIC
High Contrast DIC
DIC with circular polarized light
Total Interference Contrast
Polarization Contrast
Options
Definite Focus.2
Confocal Microscopy
- Ultra Violet
- VIS (visible light)
- NLO-IR / 2 Photon
Total Internal Reflection Fluorescence
ApoTome
Microdissection
  • Adapter M 27x0.75 / W 0.8 H
    Adapter M 27x0.75 / W 0.8 H "0"
    Item no.: 000000-1095-168
  • Coverglass cap D = 0.17 - 0.6 mm
    Coverglass cap D = 0.17 - 0.6 mm
    Item no.: 422902-9901-000
Mechanical Dimensions
Transmittance curve
LD A-Plan

The series with large working distance represent the entry level for inverted microscopy. They are corrected for cover glass and vessel bottom thickness up to 2 mm. This means optimal in the main applications of LD objectives, such as observation through thicker cell culture vessels etc. But also the use of thinner cover glasses for example in the range of 0.17 to 0.6 mm is easily possible with the simple use of a cover glass cap. The available contrast methods are ranging from brightfield, phase contrast to VAREL, Hoffman Contrast up to “PlasDIC”, the Zeiss exclusive polarization optical differential interference contrast, that makes applications like ICSI now possible even in plastic vessels with high resolution and brilliant contrast. Of course they are also suitable for fluorescence applications with excitation wavelengths within the visible spectrum.

Objective LD A-Plan 32x/0.4 Ph1 Var1 (D=0.6-1.4mm) (WD=3.2mm at D=1mm)
