Cámara microscópica Axiocam 506 mono (D)

Cámara microscópica Axiocam 503 mono (D)

Microscopy Camera Axiocam 202 mono Most versatile monochrome camera for education, documentation and routine applications with standalone capability, USB3.0 and Ethernet connectivity with 64bit driver software for: ZEN (blue edition) and Labscope. Camera package contains the following accessories: - USB 3.0 hub Type-C, - USB 3.0 flash drive, Type-C and Type-A - USB 3.0 cable Type-C to Type-A - Power <(>&<)> signal cable camera to microscope stand compatible with Axiolab 5 and Axioscope 5/7/Vario and, - Power adapter with country-specific plug Sensor: Sony CMOS image sensor Monochrome, Global Shutter Number of Pixel: 1920 (H) x 1080 (V) = 2MP, Full HD (1080p) Selectable Resolution: 1920 x 1080 = Full HD (1080p) Pixel size: 5.86 µm x 5.86 µm Effective Area: 11.25 mm x 6.33 mm, equivalent to 1/1.23'' (13 mm diagonal) Spectral range: approx. 350 nm – 850 nm, protection glass (coated) Control buttons on camera for stand-alone use: 1x Image capture 1x OSD (On Screen Display menu) 1x Camera factory reset Status-LED for camera: color coded operation status Stand-alone: Image storage format: TIFF or JPG Video stream format: mp4 Live frame rate via HDMI: 30 fps @ 1080p Live frame rate through software via Ethernet or USB 3.0 (depending on hardware and software configuration), Exp. Time 1 ms: H x V Frame rate 1920 x 1080 up to 30 fps (Labscope, ZEN) Digitization: 12-bit or 8-bit A/D conversion Integration time: 0.30 ms up to 2 s Gain: 1x - 16x Interfaces for Communication and for Power: HDMI for monitor USB 3.0 Type C for USB hub, flash drive, Wi-Fi adapter or, PC connection Ethernet (RJ45) for LAN connection Micro-D for power and communication with dedicated stands Optical interface: C-mount Max. file size per image: 12 bit .tiff: 4 MB (one channel, not content dependent) 8 bit .tiff: 2 MB (one channel, not content dependent) 8 bit .jpg: approx. 0.1 MB – 1.3 MB (content dependent) Size/Weight: approx. 135 x 97 x 54mm / 590 g Housing: Blue painted aluminum and cooling fins on the top plate Registration: CE, RoHS, CSA Power supply: via Micro-D interface Power consumption: 9 W (24 V DC, 0.75 A) Environmental conditions: +10°C to +40°C, max. 75% relative air humidity at 35°C, no condensation, free air circulation required, indoor use Operating systems for ZEN: Windows 10 x64 Prof./Ultimate and higher for Labscope: Windows 7/10 x64 Prof./Ultimate and iOS v11 and higher Supported Application Software: ZEN blue v3.0 and higher (includes ZEN lite/pro/system) Labscope v2.9 (win) v2.8.3 (iOS) and higher The camera is network-enabled and can be used with the ZEISS iOS App and Labscope software. The App is available as a free download from the Apple App Store. Unless otherwise stated by the distributor, iPad and WLAN router are not supplied by ZEISS.

EMCCD Cámara evolve 512 delta (D)

Cámara microscópica AxioCam ICm 1 Rev.1 FireWire (D)

EMCCD Cámara QImaging Rolera em-c2 (D) Cámara monocroma Low Light Live Cell Imaging con interfaz FireWire B / IEEE1394b PCIe, cable de 3 m y caja de disparo con conexiones BNC. Sensor de imagen EMCCD: Texas Instruments TX285 transferencia de marco CCD con EM Gain, número de píxeles: 1004 (H) x 1002 (V) - Tamaño de píxel: 8 µm x 8 µm Tamaño del chip: 8 mm x 8 mm Sensibilidad espectral: 380 hasta 1050 nm. Cantidad máx. de carga por píxel: aprox. 32 ke Full Well Capacity Resolución ajustable: H x V Factor Binning 125 x 125 8 x 8 250 x 250 4 x 4 500 x 500 2 x 2 1004 x 1002 1 x 1 Lectura de regiones del sensor (''ROI''): Digitalización de definición libre: 14 bit / 40 MHz Ruido de lectura: 18 e- rms / 10 MHz 25 e- rms / 20 MHz 28 e- rms / 40 MHz Ruido de lectura reducido de forma efectiva a <(><<)> 1 e- rms con EM Gain activo. Función ''Easy EM'' para el ajuste previo de un valor EM Gainóptimo para diferentes velocidades de lectura (sólo para ZEN) Corrientede oscuridad: 0.06 e-/p/s @ -50°C Tiempo de integración: 200 µs hasta 600 s Enfriamiento: -50 °C (regulado) Conexión de señal de control: salida TTL para el control de los cierres eléctricos externos Interfaz: FireWire / IEEE1394b, conector hembra de 9 pines, cable de 3 m, 800 Mbit/s Interfazóptica: Montura C Tamaño/ peso: aprox. 15 cm x 7,6 cm x 6,4 cm (5,9'' x 3,0'' x 2,5'') / 1 kg Carcasa: Rosca de 1/4'' para adaptador de trípode Homologaciones: CE, FCC Alimentación de corriente: fuente de alimentación AC 100 - 240 V, DC 12 V / 5 A, 60 W con enchufe específico del país Condiciones ambientales 0° ... +25 °C, 0% .... 80% de humedad ambiental relativa, sin condensación, el aire debe poder circular libremente

Cámara microscópica Axiocam 702 mono (D)

EMCCD Cámara evolve 512 (D)
