Stereomicroscope SteREO Discovery.V8
Item no.: 495015-0020-000 (individual configuration)Stereomicroscope SteREO Discovery.V8 with objective nosepiece S, coax
Stereomicroscope SteREO Discovery.V8
Item Number: 495015-0020-000 (individual configuration) Reset configurationTip
Current configuration
-
Cold-light source CL 6000 LED (D)
Item no.: 435700-9101-000Cold-light source CL 6000 LED (D)
Item Number: 435700-9101-000Cold-light source CL 6000 LED (D) - up to 600 lm light flux at 9 mm fiber output dia., ca. 6200K color temperature - min. 50,000 operating hours until intensity drop to 70% - control of intensity and 6 memory cells by rotary push knob and LCD - 10 mm collet chuck with sensor for 1500 light guides - filter slider for 2 mounted filters 35x26x4 mm and with free opening - max. 70W wide-range supply for flicker free light, silent fan - 2.5 mm jack bush for on/off via optional foot button S, USB socket - country-specific mains cord - Dimensions D241xW192xH118 mm, weight 3.1 kg
-
Eyepiece PL 16x/16 Br. foc.
Item no.: 444054-9000-000Eyepiece PL 16x/16 Br. foc.
Item Number: 444054-9000-000Eyepiece PL 16x/16 Br. foc.
-
Eyepiece eyecup
Item no.: 444801-0000-000Eyepiece eyecup
Item Number: 444801-0000-000Eyepiece eyecup
-
SteREO Discovery.V8 microscope body
Item no.: 435000-0000-000SteREO Discovery.V8 microscope body
Item Number: 435000-0000-000SteREO Discovery.V8 microscope body Apochromatic stereo telescope system with 76 mm mount diameter, with 8:1 zoom (1.0x ... 8.0x) manually operable on both sides and switchable click stops at 1x-1.25x-1.6x-2x-2.5x-3.2x-4x-5x-6.3x-8x
-
Binocular phototube S 20°
Item no.: 435107-0000-000Binocular phototube S 20°
Item Number: 435107-0000-000Binocular phototube S 20° for 51-75mm eye distance and with 100/100 switchover of the right channel to interface 60N
-
Objective Plan S 1.0x FWD 81 mm
Item no.: 435200-0000-000Objective Plan S 1.0x FWD 81 mm
Item Number: 435200-0000-000Objective Plan S 1.0x FWD 81 mm (137 mm parfocal length)
-
Objective Achromat S 1.25x FWD 50mm
Item no.: 435220-0000-000Objective Achromat S 1.25x FWD 50mm
Item Number: 435220-0000-000Objective Achromat S 1.25x FWD 50mm (93 mm parfocal length)
-
Objective nosepiece S, coax 3x2 cod
Item no.: 435303-9000-000Objective nosepiece S, coax 3x2 cod
Item Number: 435303-9000-000Objective nosepiece S, coax 3x2 cod for stereo and axial mode with 3 objectives on SteREO Discovery, switchable coaxial epi-illumination incl. light guide 1500, 2x 4.5/1000mm, to mount at focus drive with profile column as an alternative of 435402 carrier S or 435116 co-observer equipment
-
Intermediate Y-tube S mot
Item no.: 435103-9030-000Intermediate Y-tube S mot
Item Number: 435103-9030-000Intermediate Y-tube S mot motorized change (at push of its button or via CAN command from nosepiece 435302 or 435303-9000) between stereoscopic viewing (3D) and binocular vertical viewing (2D) through the right channel of Discovery body; powersupply by CAN distributor or power supply plug CAN RJ45, 000000-0514-784; incl. 2 cables 0.5m and 1m
-
Coarse/fine drive with column S 490mm
Item no.: 435400-9901-000Coarse/fine drive with column S 490mm
Item Number: 435400-9901-000Coarse/fine drive with column S 490mm - Lifting range 340 mm, load capacity 10 kg - For stand bases 300/450
-
Power supply plug CAN RJ45 DC 24V 30W (D)
Item no.: 000000-0514-784Power supply plug CAN RJ45 DC 24V 30W (D)
Item Number: 000000-0514-784Power supply plug CAN RJ45 DC 24V 30W (D) for power supply of any coupled CAN items S; incl. mains input plug EU, GB, USA/J, AUS in cardboard box
-
Base 300 for epi-illumination
Item no.: 435433-9401-000Base 300 for epi-illumination
Item Number: 435433-9401-000Base 300 for epi-illumination WxDxH 290x353x25mm stand base with 2x M8 threaded holes and b/w plate D=120mm; compatible to T column 350mm and central column S 490mm; VisiLED transmitted light (417095-9400) mountable from below, in addition glass plate D=120mm (435501-0002); stage d=84mm needs adapter 84/120 (435430-9010) additionally
-
High Power LED Ring Illuminator, segmentable (HPRL) (D)
Item no.: 417040-9300-000High Power LED Ring Illuminator, segmentable (HPRL) (D)
Item Number: 417040-9300-000High Power LED Ring Illuminator, segmentable (HPRL) (D) - 8 High Power LEDs with ring optics, optics mountable for near- or far WD range - Near WD range position: FWD 45-130 mm, Illuminance typ. 220 klx (@ FWD 50 mm) - Far WD range position: FWD 80-300 mm, Illuminance typ. 170 klx (@ FWD 90 mm) - Correlated color temperature ca. 5800 K, lifetime ca. 25.000 h (lumen maintenance 70 %) - Ergonomic operation integrated in housing: no controller box needed - Encoder 1 for setting of segment modes, turning in 45° steps and auto rotation - Encoder 2 for dimming, storage and recall of one illumination setting - Separate On/Off switch - Segment modes: full, half, quarter circle, two opposite quarter circles - Interface to objective: D=66 mm - ESD socket for controlled discharge of electrostatic load - Thread to mount accessories (Polarization Filter Set, Diffusor) - incl. wide-range power supply and 4 adapters EU, US, CH, JP
-
Lambda/4 Cap S, d=66 mm
Item no.: 435112-9010-000Lambda/4 Cap S, d=66 mm
Item Number: 435112-9010-000Lambda/4 Cap S, d=66 mm for objectives S or Z, D=66 mm, reduces FWD by 7 mm; required to coaxial epi-illuminator S working in axial mode or to Epi-illuminator Z if specular samples are existing
-
Dust protection Set M
Item no.: 434303-0000-000Dust protection Set M
Item Number: 434303-0000-000Dust protection Set M consisting of dust cover (L650xW200xH570 mm), eyepiece cover and protection cap for luminous-field diaphragm optics
